Low Temp VLF Series Horizontal (Chest) Freezers

https://www.yamato-usa.com/web/image/product.template/14417/image_1920?unique=5a4ed00

0˚C to -40˚C

$ 1.00 $ 1.00

  • Model

This combination does not exist.

Contact Us

Looking for a Low Temp Chest Freezer?

Features


Variable Speed Hermetic Compressors
Temperature Hi/Low Alarm with Real-Time Email & Text Notifications

Excellent Temperature Stability

Automated Data Logging

User Access Control

CFC & HCFC free

Energy Saving
​
Intuitive Touchscreen Interface

Primary Uses

  • Laboratories
  • Research Facilities
  • Pharmaceuticals
40 years as a leading scientific lab equipment provider in the United States.
All products come with a 1 year warranty.
Every product is made through environmentally conscious methods and remains eco-friendly all throughout its life cycle.

CONTROL SPECIFICATIONS

Feature VLF Series
Temperature control system Touch screen dual display
Temperature alarm Audible high / low alarm
Alarm notification SMS / Email notification*
Remote control VNC via local network*
Control security Multi-level security
Temperature recorder Viewable temperature graph
Data download USB or FTP
Network connection Hardwire ethernet (RJ45)
Alarm relay Dry contacts
Power failure via dry contacts

*Any alarm, logging, or recording systems installed in (or on) the equipment do not power any external devices required for signal transmission; such as the modem, routers, or switches on your local network connection.

Unpowered systems will obstruct alert system functionality during a power outage. Please consult your IT department and/or internet provider for additional information on internet operation during a power outage.


GENERAL SPECIFICATIONS

Feature VLF Series
Defrost Manual
Air circulation Gravity flow
Compressor (s) Cascade-type hermetic compressor
Energy efficient variable speed
Refrigeration CFC & HCFC free
Insulation Polyurethane foam
Opening Top opening lid
Loackable lid / door Yes, with padlock
Exterior Steel, powder coated
Interior Steel, galvanized
Voltages available 115V 60H 1 Phase - NEMA 5-15
208V 60H 1 Phase - NEMA 6-15
230V 60H 1 Phase - NEMA 6-15
Other voltages available upon request


UNIQUE SPECIFICATIONS FOR ENERGY EFFICIENT CHEST TYPE (HORIZONTAL) LOW TEMPERATURE FREEZERS - TOP OPENING

Model Capacity Rack Capacity Casters Internal Dimension External Dimension
Liters Cu. ft. Lockable Inch Centimeter Inch Centimeter
VLF001C 56 2 6 4 17 x 14 x 14 43 x 35 x 35 25.25 x 25.75 x 40 64 x 65 x 101
VLF101C 83 3 8 4 24 x 12 x 18 61 x 31 x 46 34.5 x 25.25 x 48 87 x 64 x 121
VLF201C 142 5 15 4 30 x 18 x 16 76 x 46 x 40. 40.5 x 31 x 47 102 x 81. x 119
VLF301C 255 9 16 4 45.5 x 16 x 20 115 x 40 x 50 57.5 x 29 x 46.5 146 x 73 x 116
VLF401C 340 12 27 6 55 x 19 x 20 139 x 48 x 50 65.5 x 32 x 47.5 166 x 81 x 120
VLF501C 400 14 30 6 62 x 20 x 20 157 x 50 x 50 72.5 x 33 x 47.5 184 x 83 x 120
VLF601C 480 17 36 8 69 x 20 x 21 175 x 50 x 53 81.25 x 33.5 x 48 206 x 85 x 123
VLF701C 594 21 42 8 81 x 21.5 x 21 205 x 54 x 53 91 x 36 x 49 231 x 91 x 124
VLF801C 626 22 36 12 67 x 19 x 30 170 x 48 x 76 98 x 36 x 43.5 248 x 91 x 110
VLF901C 766 27 48 12 67 x 23 x 31.25 170 x 57 x 79 98 x 36 x 43.5 248 x 91 x 110

Click on the link below to download the associated PDF.


VLF Series Energy Efficient Low Temp. Freezers

Ultra Low and Low Temperature Freezers and Refrigerator Buyer’s Guide

To download Operational Manual, visit our Technical Support Center

Start with the customer – find out what they want and give it to them.

Specifications

Model VLF101C, VLF201C, VLF301C, VLF401C, VLF501C, VLF601C, VLF801C, VLF901C
